Features
25KHz/12.5KHz Switchable (Wide/Narrow Band)
FM Radio (65.0MHz-108.0MHz)
Large Tri-color LCD Display (3 Selectable Colors)
LED Flashlight
High /Low RF Power Switchable
VOX
50 CTCSS/ 104 DCS Tones
Tone searching/scanning
Dual standby
PC programmable
Transmitter time-out timer(TOT)
Busy channel lock-out(BCLO)
UV-82 SPECIFICATIONS
Frequency range:
[TX] 136 – 174MHz, 400 – 520MHz
[RX] 136 – 174MHz, 400 – 520MHz, 68-108MHz (FM Broadcast)
Channel Capacity:
128 Channels
Channel Spacing
25KHz (wide band)12.5KHz (narrow band)
Sensitivity
=0.25µV (wide band) =0.35µV (narrow band)
Operation Voltage
7.4V DC ±20%
Battery:
1800mAh
Frequency step:
2.5, 5, 6.25, 10, 12.5, 20, 25, 30 and 50KHz
Antenna:
Antenna Connector: SMA-Female / Antenna Impedance: 50O
Accessory Connector:
Kenwood 2 Pin Standard
Stability:
±2.5ppm
Output power:
5W / 1W
Audio Power Output
1000mW/10% (1 Watt)
